Kicker CXA800.1 Mono Amplifier

Unleash True Subwoofer Performance

The Kicker CXA800.1 Mono Amplifier is engineered for music lovers who demand clean, powerful, and reliable bass at an affordable price. Designed with an optimized circuit layout and high-grade internal components, this Class-D mono amp delivers up to 800 watts of thunderous power in a compact package that fits almost anywhere.

Key Features That Set It Apart

• One-Ohm Stable Design: Flexible wiring options for single or multiple subwoofers without sacrificing performance.

• Efficient Class-D Power: Maximum output with minimal heat and power consumption.

• KickEQ™ Variable Bass Boost: Add up to 6dB of extra low-end punch, perfect for bass-heavy tracks.

• Advanced 12dB Crossover: Easily tune your subwoofer frequencies for tight, clean bass response.

• 24dB Subsonic Filter: Protects your subs from harmful ultra-low frequencies.

• FIT+™ Integration Technology: Works flawlessly with nearly every factory or aftermarket radio without the need for a line-out converter.

• High-Level Input Capability: Accepts up to 40 volts of speaker-level signal for maximum installation flexibility.

• Full-Range RCA Pass-Through Outputs: Expand your system easily with additional amps or full-range speakers.

• Vertical or Horizontal Mounting: Includes hardware for unique and space-saving installations.

• CXARC Remote Bass Control Compatible: Optional dash-mounted controller lets you adjust bass on the fly.

Technical Specifications

• Model: CXA800.1

• Power Output:

  • 300W x 1 @ 4 Ohms

  • 600W x 1 @ 2 Ohms

  • 800W x 1 @ 1 Ohm

• Frequency Response: 25Hz – 200Hz, +0/-1dB

• Signal-to-Noise Ratio: >95dB, A-weighted

• Input Sensitivity: 125mV–5V (Low Level) / 1V–40V (High Level)

• Crossover: Variable Low-Pass 50Hz–200Hz (12dB/octave)

• Subsonic Filter: 25Hz (24dB/octave)

• Dimensions: 2-3/8"H x 6-3/4"W x 8-1/8"L (5.9 x 17 x 20.6 cm)

• Warranty: 2 years (Authorized Kicker Dealers or kicker.com purchase)

Why Choose the Kicker CXA800.1 Over Other Amps?

The Kicker CXA800.1 Mono Amplifier stands out by delivering true one-ohm stability, exceptional flexibility, and powerful bass output without straining your budget. Competing amplifiers in this price range often lack the same level of tuning control, integration options, or reliability under high-demand loads.

Rider Q&A

Q: Can I run multiple subwoofers with this amp?
A: Yes, the CXA800.1 is stable down to 1 ohm, making it perfect for multiple subwoofer setups.

Q: Do I need a line-out converter for my factory stereo?
A: No, thanks to FIT+™ technology, this amp works directly with speaker-level signals up to 40V.

Q: Will this amp overheat on long drives or heavy use?
A: Its Class-D efficiency keeps it running cool, even during extended bass sessions.

Q: How does this compare to other 800W amps?
A: The CXA800.1 offers more flexibility, a cleaner signal, and extra tuning features like KickEQ™ and subsonic filtering that many competitors lack.

Upgrade your car or motorcycle sound system today with the Kicker CXA800.1 Mono Amplifier, delivering massive bass power, unbeatable tuning flexibility, and proven Kicker reliability.
