DB Drive Xpert EXT1.5NH 1.5″ Mini NEO Horn Tweeter

High Output & Wide Dispersion

Compact Size, Huge Sound Impact

The DB Drive Xpert EXT1.5NH 1.5″ Mini NEO Horn Tweeter is a powerhouse of precision and volume for builds that demand maximum projection and clarity. A neodymium motor and 106 dB sensitivity deliver crisp, cutting highs with minimal amplifier power—ideal for SPL competition setups, show vehicles, motorcycles, and outdoor sound systems.

Engineered for Superior Clarity

A Poly/Mylar diaphragm paired with a 1.5″ copper voice coil ensures smooth and accurate high-frequency reproduction. The aluminum die-cast waveguide delivers wide dispersion, ensuring every listener stays in the sweet spot.

Built for Wide-Area Coverage

Horn loading plus high efficiency equals effortless reach. Whether you’re filling a car interior, a crowd, or an open outdoor space, this tweeter projects clean, distortion-free treble without harshness.

Key Features

• 1.5″ (38 mm) voice coil for strong power handling

• Neodymium magnet for lightweight, efficient output

• Poly/Mylar diaphragm for smooth, accurate highs

• 106 dB sensitivity (1W/1m) for serious SPL with modest power

• Aluminum die-cast waveguide for wide, even dispersion

• 8-ohm nominal impedance for flexible wiring

• Use a minimum 3 kHz / 12 dB high-pass crossover for protection

Specifications

• Impedance: 8 Ω

• RMS Power: 85 W

• Peak Power: 250 W

• Sensitivity: 106 dB (1W/1m)

• Voice Coil: 1.5″ (38 mm) copper

• Magnet: Neodymium

• Diaphragm: Poly/Mylar

• Waveguide: Aluminum die-cast

• Recommended HPF: 3 kHz @ 12 dB/octave or higher

Comparison Chart

F.A.Q.

Q: Is the DB Drive EXT1.5NH sold individually or as a pair?
A: It is typically sold individually. Always confirm quantity when ordering.

Q: Can I run this tweeter without a crossover?
A: No. Use at least a 3 kHz / 12 dB high-pass crossover to prevent damage.

Q: Is this tweeter suitable for motorcycles or outdoor setups?
A: Yes. The high sensitivity and horn-loaded design make it ideal for open-air environments.

Q: What type of amplifier works best with this tweeter?
A: Any quality amplifier with clean output and proper crossover settings will work.

Professional Opinion

The DB Drive Xpert EXT1.5NH is a serious performer in the SPL and pro-audio category. Its 106 dB sensitivity means you can achieve extreme volume without pushing your amplifier to the limit, and the horn-loaded design ensures wide sound coverage. This is an excellent choice for installers and competitors who need maximum projection, durability, and crisp treble reproduction in both mobile and outdoor applications.

For unmatched projection, efficiency, and clarity, choose the DB Drive Xpert EXT1.5NH 1.5″ Mini NEO Horn Tweeter.
